Rectangular Tubes
Stainless steel rectangular tubes for structural, architectural and industrial use.
Sourced worldwide and supplied across Europe and around the world, our stainless steel tubes meet international tolerance standards in both metric and imperial units - ready for structural, hygienic and architectural applications.
- Cross-section
- 20 × 10 – 300 × 100 mm
- Wall thickness
- 1.0 – 6.0 mm
- Tolerance
- ASTM A484 or as required
- Units
- Metric and imperial
Full size list - every standard cross-section - available on request.
View the full dimension table
| Cross-section (mm) | Wall from (mm) | Wall to (mm) |
|---|---|---|
| 20 x 10 | 1 | 1,5 |
| 20 x 15 | 1 | 1,5 |
| 25 x 10 | 1,5 | - |
| 25 x 15 | 1 | 2 |
| 30 x 10 | 1 | 1,5 |
| 30 x 15 | 1 | 2 |
| 30 x 20 | 1 | 2 |
| 35 x 20 | 1 | 2 |
| 40 x 10 | 1,5 | 2 |
| 40 x 15 | 1 | 2 |
| 40 x 20 | 1 | 3 |
| 40 x 25 | 1,5 | 2 |
| 40 x 27 | 1,5 | - |
| 40 x 30 | 1 | 3 |
| 50 x 10 | 1,5 | - |
| 50 x 15 | 1,5 | - |
| 50 x 20 | 1 | 2 |
| 50 x 25 | 1,2 | 3 |
| 50 x 30 | 1 | 3 |
| 50 x 40 | 1,2 | 3 |
| 60 x 20 | 1,2 | 2 |
| 60 x 30 | 1,2 | 3 |
| 60 x 40 | 1,2 | 4 |
| 70 x 20 | 1,5 | 3 |
| 70 x 30 | 1,5 | 4 |
| 70 x 40 | 2 | 3 |
| 80 x 20 | 1,5 | 2 |
| 80 x 30 | 2 | 4 |
| 80 x 40 | 1,2 | 6 |
| 80 x 50 | 2 | 6 |
| 80 x 60 | 2 | 5 |
| 100 x 20 | 2 | - |
| 100 x 30 | 2 | 3 |
| 100 x 40 | 2 | 5 |
| 100 x 50 | 2 | 6 |
| 100 x 60 | 2 | 5 |
| 100 x 80 | 2 | 5 |
| 120 x 40 | 2 | 4 |
| 120 x 60 | 2 | 6 |
| 120 x 80 | 2 | 5 |
| 140 x 60 | 2 | 4 |
| 140 x 80 | 3 | 6 |
| 150 x 50 | 2 | 5 |
| 150 x 100 | 2 | 6 |
| 160 x 80 | 2 | 6 |
| 180 x 60 | 2 | 4 |
| 200 x 100 | 2 | 6 |
| 200 x 150 | 3 | 6 |
| 250 x 100 | 3 | 6 |
| 250 x 150 | 3 | 6 |
| 300 x 100 | 3 | 6 |
More Stainless Steel
Explore the full range
Request a rectangular tubes quote
Send us your requirements and our team will send you a tailored quote - with availability, sourcing options and pricing - shortly.
